ACM Rolling Shutter Central Motor 210 KG 260 Nm
Price 900 AEDIn Stock
ACM 210 KG 260 Nm Heavy-Duty Rolling Shutter Central Motor UAE
ACM 210 KG 260 Nm Rolling Shutter Central Motor is a heavy-duty automatic shutter motor designed for compatible rolling shutters with a lifting capacity of up to approximately 210 KG. Delivering 260 Nm torque from a 230V power supply, this model is suitable for shops, warehouses, workshops, large garages and commercial rolling shutter applications.
The ACM central motor mounts directly on the rolling shutter shaft, providing a compact and powerful automation solution. It can be used for new rolling shutter installations or replacement of compatible existing central motors.
ACM 260 Nm Rolling Shutter Motor Characteristics
- ACM rolling shutter central motor
- Maximum lifting capacity: up to 210 KG
- Motor torque: 260 Nm
- 230V AC power supply
- 76 mm rolling shutter tube
- 240 mm pulley / spring box
- 120 mm × 2 spindles
- Central shaft-mounted motor design
- Automatic shutter opening and closing
- Manual emergency operation during power failure
- Compatible with suitable wall-switch controls
- Remote operation possible with compatible receiver/controller
- Suitable for commercial and heavy-duty shutter applications
ACM 210 KG 260 Nm Technical Specifications
| Brand | ACM |
| Product Type | Rolling Shutter Central Motor |
| Lifting Capacity | Up to 210 KG |
| Torque | 260 Nm |
| Power Supply | 230V AC |
| Rolling Tube | 76 mm |
| Pulley / Spring Box | 240 mm |
| Spindles | 120 mm × 2 |
| Operation | Automatic / Manual Emergency Operation |
| Control Options | Wall Switch / Compatible Remote Control System |
| Applications | Shops, Warehouses, Workshops, Garages & Commercial Rolling Shutters |
Key Features of ACM 210 KG Central Motor
- Powerful 260 Nm torque output
- Up to 210 KG lifting capacity
- Heavy-duty 230V motor
- 76 mm rolling tube configuration
- 240 mm pulley / spring box
- Dual 120 mm spindle configuration
- Compact central shaft installation
- Suitable for larger rolling shutters
- Manual operation available during power failure
- Wall switch and compatible remote-control options
Heavy-Duty Rolling Shutter Motor for Shops
The ACM 210 KG central motor is suitable for larger shopfront rolling shutters where more lifting capacity is required than the ACM 125 KG, 140 KG or 180 KG models.
The shutter should be properly balanced and the motor selected according to the total curtain weight, shaft arrangement, spring system and daily operating requirements.
ACM 260 Nm Motor for Warehouses
With 260 Nm torque, this ACM central motor is suitable for compatible warehouse, workshop and commercial rolling shutters requiring higher lifting performance.
For substantially heavier industrial shutters or applications with demanding operating cycles, a higher-capacity motor or dedicated rolling shutter side motor should be selected.
ACM Motor for Large Garage Rolling Shutters
The ACM 260 Nm motor can also automate compatible large residential and commercial garage roller shutters. Correct shutter balancing is particularly important for reliable operation and long motor service life.
Wall Switch & Remote Control Operation
The ACM central motor can be operated using a compatible up / stop / down wall switch. Wireless operation can also be added using a suitable rolling shutter controller, radio receiver and remote control.
Remote-control functionality depends on the control equipment installed with the motor. A built-in radio receiver should only be stated when the supplied controller specifically includes one.
Manual Operation During Power Failure
The motor provides manual emergency operation during electrical power failure. This allows the rolling shutter to be manually operated when mains power is unavailable, provided the shutter and motor have been correctly installed and balanced.
ACM Central Motor Range
| Model | Lifting Capacity | Torque |
|---|---|---|
| ACM Central Motor | 125 KG | 140 Nm |
| ACM Central Motor | 140 KG | 170 Nm |
| ACM Central Motor | 180 KG | 190 Nm |
| ACM Central Motor | 210 KG | 260 Nm |
| ACM Central Motor | 240 KG | 420 Nm |
Choosing the Correct ACM Rolling Shutter Motor
The correct rolling shutter motor should be selected according to the actual shutter weight, shutter dimensions, tube diameter, spring configuration, shutter balance and operating frequency.
Do not select a motor based only on shutter width and height. The total curtain weight and mechanical condition of the shutter are important factors in achieving reliable operation.
ACM 210 KG Rolling Shutter Motor Supply & Installation UAE
We supply and install ACM 210 KG 260 Nm rolling shutter central motors across the UAE for shops, warehouses, workshops, garages and commercial properties.
Supply, replacement, installation and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
For replacement applications, send the existing motor label, shutter dimensions, shaft diameter and installation photos so the correct ACM central motor can be confirmed.
