BEA EAGLE 5+ Radar Motion Sensor in UAE

• The BEA EAGLE 5+ is an advanced opening radar sensor
• suitable for all types of automatic doors, including sliding and swing doors.
• It uses microwave technology with a microprocessor,
• delivering stable and reliable motion detection.
• The unidirectional detection mode ensures
• that only approaching movements activate the door,
• improving efficiency and reducing unnecessary openings.

Key Features:

• Microwave radar motion detection (24.150 GHz)
• Unidirectional detection (approaching movement only)
• High stability with BEA planar antenna
• Adjustable detection field size & shape
• Energy-saving operation (reduces heat loss)
• Suitable for sliding & swing automatic doors
• Flexible mounting: ceiling or floor installation
• Ignores door closing movement (hinge mounting)
• Compact, durable ABS housing (IP54 rated)

Technical Specifications:

• Technology: Microwave + Microprocessor
• Transmitter Frequency: 24.150 GHz
• Radiated Power: < 20 dBm EIRP
• Power Density: < 5 mW/cm²
• Detection Mode: Motion
• Minimum Detection Speed: 5 cm/s
• Power Supply:
• 12–24V AC ±10%
• 12–24V DC +30% / -10%
• Mains Frequency: 50–60 Hz
• Power Consumption: < 2 W
• Output: Relay (change-over contact)
• Max Voltage: 42V AC/DC
• Max Current: 1A
• Max Power: 30W (DC) / 42VA (AC)
• Mounting Height:
• EAGLE ONE: 1.8 m – 4 m
• EAGLE ONE HM: 4 m – 5 m
• Protection Rating: IP54
• Operating Temperature: -20°C to +55°C
• Dimensions: 120 × 80 × 50 mm
• Tilt Angles:
• Vertical: 0° to 90°
• Lateral: -30° to +30°
• Material: ABS
• Weight: 215 g

Applications in UAE:

• The BEA EAGLE 5+ Radar Sensor is ideal for:
• Automatic sliding glass doors
• Swing door automation systems
• Hospitals & healthcare facilities
• Shopping malls & retail stores
• Office buildings & commercial entrances
• Industrial automatic doors

Why Choose BEA EAGLE 5+?

• Reliable and precise motion detection
• Energy-efficient operation (smart detection filtering)
• Reduces unnecessary door openings
• Easy installation and adjustment
• Durable design for indoor & outdoor use

Package Includes:

• BEA EAGLE 5+ Radar Sensor
• Mounting Accessories
• User Manual
