BEA EAGLE ARTEK Radar Sensor for Automatic Doors

BEA EAGLE ARTEK 24.15 GHz Automatic Door Radar Sensor UAE

BEA EAGLE ARTEK is a compact professional microwave radar opening sensor designed for automatic pedestrian doors. Using 24.15 GHz radar technology, it provides reliable motion detection and unidirectional automatic door activation for sliding, swing, folding and revolving door applications.

The EAGLE ARTEK combines a slim 120 × 50 × 50 mm housing with electronically adjustable detection fields, simple push-button programming and advanced filtering designed to reduce unwanted activations. It is an ideal automatic door opening sensor for retail stores, shopping malls, hospitals, hotels, offices and other commercial entrances.

BEA EAGLE ARTEK Key Features

• Genuine BEA automatic door radar sensor
• Model: EAGLE ARTEK
• 24.15 GHz microwave radar technology
• Unidirectional automatic door opening
• Motion detection technology
• Electronic detection-field adjustment
• Simple push-button configuration
• Wide and narrow detection field options
• Improved filtering to reduce false detections
• Minimum detection speed: 5 cm/s
• 12–24V AC/DC power supply
• Low power consumption below 1W
• Solid-state relay output
• Mounting height from 1.8m to 4m
• IP54 protection rating
• Slim and compact ABS housing

BEA EAGLE ARTEK Technical Specifications

24.15 GHz Microwave Radar Technology

The BEA EAGLE ARTEK uses professional 24.15 GHz microwave radar technology to detect pedestrian movement in front of an automatic entrance. When approaching movement enters the configured detection zone, the sensor sends an activation signal to the compatible automatic door controller.

Unidirectional Automatic Door Opening

A key feature of the EAGLE ARTEK is unidirectional opening detection. The sensor can focus on approaching pedestrian movement instead of unnecessarily activating the door for people moving away from the entrance.

This helps optimise automatic door opening and closing cycles and can reduce unnecessary door operation and associated energy loss.

Electronic Detection Field Adjustment

The EAGLE ARTEK provides convenient electronic detection-field adjustment. Unlike older radar sensors that may require manual antenna changes to alter the field shape, the ARTEK allows flexible configuration using its push-button controls.

Wide & Narrow Detection Fields

The sensor supports different detection-field configurations to suit the entrance layout. BEA specifies a maximum wide field of approximately 4m × 2m and a narrow field of approximately 2m × 2.2m at a 2.2m installation height under specified conditions.

This allows the sensor to be adapted to wide commercial entrances as well as narrower automatic door openings.

Improved Filtering & Reduced False Activations

BEA's ARTEK radar technology incorporates improved filtering designed to provide stable field performance and reduce unwanted detections. Fewer unnecessary activations can help improve automatic door efficiency, particularly at busy commercial entrances.

Automatic Sliding Door Sensor

The BEA EAGLE ARTEK is an excellent opening sensor for automatic sliding glass doors. Its slim housing allows discreet installation above the door while providing a configurable pedestrian activation field.

Typical installations include retail stores, shopping malls, supermarkets, hospitals, hotels, offices and commercial buildings.

Automatic Swing & Folding Door Sensor

The EAGLE ARTEK can also be installed as an opening sensor for compatible automatic swing and folding door systems. Detection-field configuration should be adjusted according to the door movement and entrance layout.

Automatic Revolving Door Sensor

BEA also supports EAGLE ARTEK applications on automatic revolving doors. Its compact housing and configurable radar field make it suitable for professional revolving-door activation applications.

12–24V AC/DC Operation

The EAGLE ARTEK supports 12–24V AC and 12–24V DC supplies, allowing integration with many professional automatic door operators. Maximum power consumption is less than 1 watt, making it an efficient automatic door activation sensor.

Solid-State Relay Output

The sensor uses a polarity-free solid-state relay output with a maximum switching rating of 30V AC / 42V DC and 100mA resistive. Always verify the automatic door controller activation input before wiring.

Compact 120 × 50 × 50 mm Design

Measuring only 120 × 50 × 50 mm and weighing approximately 120g, the EAGLE ARTEK has a slim, discreet design suitable for modern automatic glass-door installations.

BEA EAGLE ARTEK Applications

• Automatic sliding glass doors
• Automatic swing doors
• Automatic folding doors
• Automatic revolving doors
• Shopping malls and retail stores
• Supermarkets
• Hospitals and clinics
• Hotels
• Office buildings
• Commercial entrances
• Public buildings

BEA EAGLE ARTEK Replacement Sensor

The EAGLE ARTEK can be used for new compatible automatic door installations or as a replacement radar opening sensor. Before replacing an existing sensor, confirm the available power supply, controller activation input, wiring and mounting arrangement.

BEA EAGLE ARTEK Supply & Installation UAE

We supply BEA EAGLE ARTEK automatic door radar sensors throughout the UAE for automatic sliding, swing, folding and revolving door systems.

Supply, replacement, installation and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.

For replacement enquiries, provide a clear photo of the existing sensor and automatic door operator/controller so compatibility can be checked before ordering.
