SOMMER S 330/8/92 NHK 330Nm Tubular Motor
Price 1,999 AEDIn Stock
SOMMER S 330/8/92 NHK Rolling Shutter Tubular Motor UAE
SOMMER S 330/8/92 NHK is a heavy-duty 230V tubular rolling shutter motor designed for commercial and industrial roller shutter automation. The motor delivers 330 Nm torque, operates at 8 rpm and has a nominal motor diameter of 92 mm.
The tubular design allows the motor to be installed inside a compatible rolling shutter barrel, providing a compact and professional automation solution for shop shutters, warehouses, factories, garages and commercial roller doors. The NHK manual override allows the shutter to be operated manually using an emergency hand crank when mains power is unavailable.
SOMMER S 330/8/92 NHK Key Features
- Original SOMMER tubular rolling shutter motor
- Model: S 330/8/92 NHK
- Rated torque: 330 Nm
- Motor speed: 8 rpm
- Nominal motor diameter: 92 mm
- Power supply: 230V AC
- Frequency: 50 Hz
- Single-phase tubular motor
- Permitted short-time operation: 4 minutes
- Protection rating: IP44
- Connection cable length: 2.5 m
- Connection cable: 4 × 0.75 mm²
- Emergency manual operation with hand crank
- Suitable for commercial and industrial rolling shutters
- Suitable for compatible shutters up to approximately 350 kg*
*Maximum shutter weight depends on shutter construction, barrel diameter, guides, friction, curtain type and installation geometry.
SOMMER S 330/8/92 NHK Technical Specifications
| Brand | SOMMER |
| Model | S 330/8/92 NHK |
| Product Type | Rolling Shutter Tubular Motor |
| Rated Torque | 330 Nm |
| Motor Speed | 8 rpm |
| Motor Diameter | 92 mm |
| Operating Voltage | 230V AC |
| Frequency | 50 Hz |
| Phase | Single Phase |
| Permitted Operating Time | 4 Minutes |
| Protection Rating | IP44 |
| Connection Cable Length | 2.5 m |
| Connection Cable | 4 × 0.75 mm² |
| Manual Emergency Operation | NHK Hand Crank |
| Recommended Shutter Capacity | Up to Approx. 350 kg* |
| Application | Rolling Shutters / Roller Doors / Commercial & Industrial Doors |
330 Nm Heavy-Duty Tubular Motor
The SOMMER S 330/8/92 NHK produces 330 Nm of rated torque, making it suitable for medium-to-heavy rolling shutter automation where a smaller tubular motor does not provide sufficient torque.
Motor selection should be based on more than shutter weight alone. The shutter curtain material, barrel diameter, shutter height, guide condition, friction and mechanical balance all affect the actual torque required.
92 mm Tubular Motor
The motor has a nominal diameter of 92 mm and is designed for installation inside a compatible rolling shutter barrel or tube.
This internal mounting design keeps the automation compact and avoids the large external footprint required by some side-mounted rolling shutter motors.
8 RPM Rolling Shutter Motor
The exact S 330/8/92 NHK model operates at 8 revolutions per minute. This is the correct SOMMER manufacturer specification for this model.
The actual shutter opening and closing speed depends on the roller barrel diameter and total shutter travel. A larger barrel circumference moves more curtain per motor revolution than a smaller barrel.
230V AC Single-Phase Motor
The SOMMER S 330/8/92 NHK operates from a 230V AC, 50 Hz single-phase power supply. This makes it suitable for many commercial and industrial shutter installations using standard mains power.
Electrical installation should include the correct isolator, protection devices, control equipment and wiring according to the motor and site requirements.
4-Minute Short-Time Duty
SOMMER specifies a permitted short-time operating duration of 4 minutes for the S 330/8/92 NHK.
This motor is intended for normal shutter opening and closing cycles rather than continuous-running industrial machinery. Repeated operation without adequate cooling can activate thermal protection or reduce motor life.
Emergency Hand Crank – NHK
The NHK version provides a manual emergency hand-crank system. If mains power is unavailable, the shutter can be operated manually using the supplied crank mechanism.
This feature is especially useful for commercial shops, warehouses, factories and garage shutters where emergency access may still be required during a power failure.
IP44 Protection
The SOMMER tubular motor has an IP44 protection rating. The installation should still protect the motor and electrical components from direct water exposure and unsuitable environmental conditions.
Correct cable routing, electrical isolation and shutter enclosure design are important for reliable long-term operation.
Suitable for Shutters Up to Approximately 350 KG
Your SOMMER S 330/8/92 NHK configuration is commonly specified for compatible rolling shutters weighing up to approximately 350 kg.
This should be treated as an application guideline rather than an absolute rating for every shutter. The actual permissible curtain weight depends on the roller diameter, shutter dimensions, curtain construction, bearings, guides and mechanical resistance.
SOMMER Tubular Motor Applications
- Commercial rolling shutters
- Industrial roller shutters
- Shopfront shutters
- Warehouse roller doors
- Factory shutters
- Workshop shutters
- Garage roller shutters
- Commercial building entrances
- Heavy-duty roller door automation
SOMMER S 330/8/92 NHK Kit Includes
- 1 × SOMMER S 330/8/92 NHK tubular motor
- 1 × Emergency manual hand crank
Rolling Shutter Control Options
The SOMMER tubular motor can be integrated with compatible shutter control equipment according to the installation requirements.
- Wall-mounted shutter switches
- Rolling shutter control units
- Compatible radio receivers
- Remote controls
- Key switches
- Wi-Fi shutter controllers
- Access-control systems
Replacement SOMMER Tubular Motor
The S 330/8/92 NHK can also be considered as a replacement for a compatible existing rolling shutter tubular motor.
Before replacement, confirm the existing motor torque, motor diameter, speed, voltage, roller tube dimensions, drive adapter, crown arrangement and emergency manual override system.
Professional SOMMER Tubular Motor Installation
Professional installation is recommended because a tubular shutter motor must be correctly fitted inside the roller tube and aligned with the shutter shaft.
The installer should also inspect the curtain, guide rails, bearings, barrel, mounting brackets, electrical wiring and manual emergency mechanism before commissioning the shutter.
SOMMER S 330/8/92 NHK Tubular Motor UAE
We supply SOMMER S 330/8/92 NHK tubular rolling shutter motors throughout the UAE for commercial and industrial roller shutter applications.
Supply, professional installation, replacement, maintenance and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
Before Ordering: Confirm the shutter width, height, approximate curtain weight, roller tube diameter, shaft configuration and existing motor specifications to ensure the S 330/8/92 NHK is suitable for the installation.
