Rolling Shutter Side Motor 600 KG

600 KG Heavy-Duty Rolling Shutter Side Motor UAE

The Rolling Shutter Side Motor 600 KG is a powerful automatic shutter motor designed for commercial and industrial roller shutter doors with lifting requirements up to 600 KG. Its side-mounted design makes it suitable for shops, warehouses, factories, workshops, garages and commercial entrances throughout the UAE.

This heavy-duty 220V rolling shutter motor provides reliable opening and closing operation with a strong gearbox, electric braking system and manual chain operation for emergency use during a power failure. It can be connected to a compatible rolling shutter controller, wall push button and remote-control receiver for convenient OPEN, STOP and CLOSE operation.

Rolling Shutter Side Motor 600 KG Key Features

• Maximum lifting capacity: 600 KG
• Heavy-duty side-mounted shutter motor
• 220V / 50Hz AC operation
• Suitable for commercial and industrial rolling shutters
• Strong reduction gearbox
• Electric brake for controlled shutter operation
• Manual chain operation during power failure
• Opening and closing limit-switch system
• Compatible with OPEN / STOP / CLOSE controls
• Compatible with suitable remote-control receivers
• Can be integrated with wall push-button controls
• Suitable for automatic roller shutter doors
• Professional installation available across UAE

600 KG Rolling Shutter Side Motor Technical Specifications

600 KG Automatic Roller Shutter Motor

The 600 KG rolling shutter side motor is designed for larger shutter doors that require more lifting capacity than smaller residential or light-commercial motors. It is suitable for many commercial and industrial shutter installations where dependable daily opening and closing is required.

The correct motor should always be selected according to the actual shutter weight, shutter width and height, shaft arrangement, operating frequency and installation configuration. The 600 KG figure represents the motor's maximum lifting class and should not be used as the only selection factor.

220V Rolling Shutter Motor

This side-mounted shutter motor operates from a 220V AC power supply, making it suitable for many standard commercial rolling shutter installations in the UAE.

The electrical supply, controller, motor wiring and safety equipment should be installed by a qualified technician according to the motor configuration and site requirements.

Manual Chain Operation During Power Failure

A key advantage of a side-mounted rolling shutter motor is the manual chain override. If electrical power is unavailable, the shutter can be operated manually using the emergency chain mechanism.

This is particularly useful for shops, warehouses, factories and commercial properties where access may still be required during a power interruption.

Electric Brake & Limit Switch System

The motor uses an electric braking system to help control the shutter during normal operation. An adjustable limit-switch mechanism is used to set the required fully open and fully closed positions.

Correct limit-switch adjustment is essential during installation to prevent the shutter from travelling beyond its intended opening or closing positions.

Remote Control & Push Button Operation

The 600 KG side motor can be used with a compatible rolling shutter controller and remote receiver to provide convenient wireless control.

Depending on the selected controller, the shutter can be operated using OPEN, STOP and CLOSE commands from a handheld remote control or wired wall push button.

600 KG Rolling Shutter Motor Applications

• Retail shop rolling shutters
• Warehouse shutter doors
• Factory entrances
• Commercial roller shutters
• Workshop shutters
• Storage facility doors
• Large garage roller doors
• Commercial building entrances
• Loading and service entrances
• Industrial rolling shutters

How to Select the Correct Rolling Shutter Motor

Do not select a shutter motor only from the door width. The correct motor capacity depends on several factors including the total shutter curtain weight, shutter height, shaft diameter, drum arrangement, guide condition, daily operating frequency and power supply.

If replacing an existing motor, check the specification label on the old motor and compare the lifting capacity, voltage, shaft arrangement and mounting dimensions before ordering.

600 KG Rolling Shutter Side Motor UAE

We supply 600 KG rolling shutter side motors throughout the UAE for shops, warehouses, factories, garages, workshops and commercial rolling shutter doors.

Professional supply, installation, replacement and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.

Before Ordering: Send the shutter width, height, approximate weight, shaft details, existing motor label and site photos so the correct rolling shutter motor can be selected.
