Rolling Shutter Side Motor 1000 KG

1000 KG Heavy-Duty Rolling Shutter Side Motor UAE

Rolling Shutter Side Motor 1000 KG is a heavy-duty automatic shutter motor designed for commercial and industrial rolling shutter doors with lifting requirements up to 1000 KG. It provides powerful and reliable operation for shops, warehouses, factories, garages, workshops and other large roller shutter applications.

The motor operates on 220V AC / 50Hz and delivers approximately 809 Nm rated output torque. With precise limit-switch control, manual operation during power failure, overload protection and heavy-duty construction, it provides a practical automation solution for large rolling shutter doors throughout the UAE.

Rolling Shutter Side Motor 1000 KG Key Features

• Maximum lifting capacity: 1000 KG
• Heavy-duty side-mounted rolling shutter motor
• Power supply: 220V AC / 50Hz
• Input power: 1013W
• Rated output torque: 809 Nm
• Rated current: 4.9A
• Rated output speed: 3.5 r/min
• Maximum lifting height: 8 metres
• Continuous working time: 7 minutes
• Accurate upper and lower limit control
• Manual operation during power failure
• Overheat and overload protection
• Low-noise operation
• Anti-fall safety design
• Suitable for commercial and industrial shutters

1000 KG Rolling Shutter Motor Technical Specifications

1000 KG Heavy-Duty Lifting Capacity

This rolling shutter side motor is designed for compatible shutters requiring lifting capacity up to 1000 KG. It is suitable for larger commercial and industrial rolling shutter installations where a smaller shutter motor does not provide sufficient capacity.

The correct motor should always be selected according to the actual shutter weight, dimensions, shaft arrangement, drum configuration, operating frequency and installation conditions.

Powerful 809 Nm Output Torque

The motor delivers approximately 809 Nm rated output torque with a rated output speed of 3.5 r/min. This combination provides the high torque required for compatible heavy rolling shutter applications.

220V AC Rolling Shutter Motor

The 1000 KG side motor operates from a 220V AC / 50Hz power supply with approximately 1013W input power and 4.9A rated current.

The electrical supply, protection devices and wiring should be installed according to the motor requirements and local electrical regulations.

Accurate Limit Switch Control

The motor incorporates an adjustable limit-switch system for setting the fully open and fully closed shutter positions. Correct adjustment helps the motor stop automatically at the required upper and lower positions.

Manual Operation During Power Failure

A manual operating mechanism allows the rolling shutter to be operated when mains electricity is unavailable. This is particularly important for commercial and industrial entrances where emergency access may be required during a power failure.

Overheat & Overload Protection

The motor incorporates protection features designed to help protect the drive system from abnormal operating conditions. Correct shutter balancing, installation and motor selection remain essential for reliable long-term performance.

Maximum 8 Metre Lifting Height

The motor is specified for a maximum lifting height of approximately 8 metres. Actual suitability depends on the complete shutter construction, drum diameter, shutter weight and mechanical configuration.

Applications

• Warehouse rolling shutters
• Factory roller shutter doors
• Commercial shop shutters
• Industrial rolling shutters
• Workshop shutter doors
• Storage facility shutters
• Commercial building entrances
• Large garage shutters
• Loading and service entrances

Rolling Shutter Motor Controllers & Remote Controls

The motor can be combined with a compatible rolling shutter controller and remote-control receiver to provide convenient OPEN, STOP and CLOSE operation. Additional control options can include wall push buttons, wireless remotes and compatible access-control devices.

How to Select the Correct Rolling Shutter Motor

Do not select a rolling shutter motor only by the width of the door. Important factors include the total shutter weight, shutter height, shaft size, drum configuration, power supply and expected daily operating frequency.

If replacing an existing motor, check the old motor label and compare its lifting capacity, voltage, torque, speed and mounting arrangement before ordering.

Rolling Shutter Side Motor 1000 KG UAE

We supply 1000 KG rolling shutter side motors throughout the UAE for commercial and industrial roller shutter applications.

Supply, installation and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.

Before Ordering: Confirm your shutter width, height, approximate total weight, shaft arrangement and available power supply to ensure the 1000 KG side motor is suitable for the installation.
